BRIDGE RECTIFIERS


OUTLINE DRAWINGS (MEASUREMENTS)



Part Number Amp Voltage Price Paypal
DF06-605A 1A 1000V $0.50


2.0 AMPERE/RS-2
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
RS203 200 50 10 2.0 1.1 $ 0.69

RS204 400 50 10 2.0 1.1 $ 0.69

RS205 600 50 10 2.0 1.1 $ 0.69

RS206 800 50 10 2.0 1.1 $ 0.69

RS207 1000 50 10 2.0 1.1 $ 0.80


4.0 AMPERE/KBU
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU401 100 150 10 4.0 1.0 $ 0.79

KBU402 200 150 10 4.0 1.0 $ 0.83

KBU404 400 150 10 4.0 1.0 $ 0.90

KBU406 600 150 10 4.0 1.0 $1.17

KBU408 800 150 10 4.0 1.0 $1.30

KBU410 1000 150 10 4.0 1.0 $1.40


6.0 AMPERE/KBJ
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBJ6005 50 175 10 3.0 1.0 $1.19

KBJ601 100 175 10 3.0 1.0 $1.19

KBJ602 200 175 10 3.0 1.0 $1.19

KBJ604 400 175 10 3.0 1.0 $1.19

KBJ606 600 175 10 3.0 1.0 $1.19

KBJ608 800 175 10 3.0 1.0 $1.19

KBJ610 1000 175 10 3.0 1.0 $1.24


6.0 AMPERE/KBU
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU6005 50 175 10 3.0 1.0 $1.19

KBU601 100 175 10 3.0 1.0 $1.19

KBU602 200 175 10 3.0 1.0 $1.19

KBU604 400 175 10 3.0 1.0 $1.19

KBU606 600 175 10 3.0 1.0 $1.19

KBU608 800 175 10 3.0 1.0 $1.19

KBU610 1000 175 10 3.0 1.0 $1.24


8.0 AMPERE/KBJ
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBJ8005 50 200 10 4.0 1.0 $1.49

KBJ801 100 200 10 4.0 1.0 $1.54

KBJ802 200 200 10 4.0 1.0 $1.59

KBJ804 400 200 10 4.0 1.0 $1.64

KBJ806 600 200 10 4.0 1.0 $1.69

KBJ808 800 200 10 4.0 1.0 $1.74

KBJ810 1000 200 10 4.0 1.0 $1.79


8.0 AMPERE/KBU
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU8005 50 200 10 4.0 1.0 $1.49

KBU801 100 200 10 4.0 1.0 $1.54

KBU802 200 200 10 4.0 1.0 $1.59

KBU804 400 200 10 4.0 1.0 $1.64

KBU806 600 200 10 4.0 1.0 $1.69

KBU808 800 200 10 4.0 1.0 $1.74

KBU810 1000 200 10 4.0 1.0 $1.79


20.0 AMPERE/KBJ
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBJ20005 50 300 10 10 1.0
KBJ2001 100 300 10 10 1.0
KBJ2002 200 300 10 10 1.0
KBJ2004 400 300 10 10 1.0
KBJ2006 600 300 10 10 1.0
KBJ2008 800 300 10 10 1.0
KBJ2010 1000 300 10 10 1.0


35.0 AMPERE/GBPC
Type

Maximum Peak Reverse Voltage

 Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25°C TA Maximum Forward Voltage @ 25°C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
GBPC3504 400 400 10 17.5 1.0 $ 5.90

GBPC3508 800 400 10 17.5 1.0 $ 6.50

GBPC3510 1000 400 10 17.5 1.0 $6.90
