RCA PLUGS AND JACKS

AUDIO PLUGS AND JACKS

RCA Plugs and Jacks

Colored plastic body RCA plugs. Max. cable dia. 4.5mm.
$0.59 /each

GW1140-yellow

GW1140-green

GW1140-blue

GW1140-white

GW1140-black

GW1140-red

Colored plastic with strain relief. Max. Cable dia. 4.5mm.
$0.53 /each

GW1141-yellow

GW1141-green

GW1141-blue

GW1141-white

GW1141-black

GW1141-red

RCA plug. Max. cable dia. 5~6mm.

GW1023-black
$2.71

RCA plug. Max. cable dia. 5~6mm.

GW1023-red
$2.71

Metal body RCA plug.
Max. cable dia. 7.5mm.

24-100
$0.99

RCA plug. Max. cable dia. 6~7mm.
Screw Terminal .no soldering

GW1107A-black
$2.90

RCA plug. Max. cable dia. 6~7mm.
Screw Terminal .no soldering

GW1107A-red
$2.90

Metal plug with strain relief.
Max. cable dia. 4.5mm.

24-104
$1.40

Color coded plug. Max. cable dia. 4~5mm

24-121-black
$1.38

Color coded plug. Max. cable dia. 4~5mm

24-122-red
$1.38

Gold plated plug with spring strain relief. Cable dia 5.5mm.

GW1130G-black
$2.25

Gold plated plug with spring strain relief. Cable dia 5.5mm.

GW1130G-red
$2.25

Color coded gold plated plug. Max cable dia. 6~7mm

GW1133G-black
$2.75

Color coded gold plated plug. Max cable dia. 6~7mm

GW1133G-red
$2.75

plastic right angle RCA plug. Max. cable dia. 5.1mm.

GW1143-black
$0.95

plastic right angle RCA plug. Max. cable dia. 5.1mm.

GW1143-red
$0.95

Crimp RCA plug for RG59/u.

24-116
$0.89

RCA jack Max. cable dia.4~5mm

GW1201-black
$0.50

RCA jack Max. cable dia.4~5mm

GW1201-red
$0.50

Metal body RCA jack.
Max. cable dia. 7.5mm

24-150
$0.99

Color coded gold plated jack.
Max cable dia. 6~7mm

GW1197G-black
$2.25

Color coded gold plated jack.
Max cable dia. 6~7mm

GW1197G-red
$2.25

Chassis mount RCA jack. 6mm mounting hole.

24-180-red	$0.83
24-180-black	$0.83

RCA jack Max. cable dia.4~5mm

GW1198-black
$1.74

RCA jack Max. cable dia.4~5mm

GW1198-red
$1.74

Gold plated chassis RCA jack. 6mm mounting hole.

24-181-red	$0.95
24-181-black
24-181-green
24-181-blue
24-181-yellow

PC mount RCA jack.

24-191
$0.60

PC mount RCA jack.

24-192
$0.60

Right angle PC mount RCA jack.
24-195-0 has a black insulator.

24-195
$0.53

Phenolic insulated RCA jack
1P
36x22mm

GW1530
$1.00
(Sold out)

Phenolic insulated
RCA jack
2P
55x21mm

GW1531
$1.90

Phenolic insulated
RCA jack
4P
49x36mm

GW1534
$2.10

Right angle PC mount RCA jack.

RCA-3
$1.00

Phenolic insulated
Right angle PC mount RCA jack
4P
37x30mm

GW1534P
$2.10

2.5mm Jacks and Plugs
Mono plug 23 x 8mm dia. Cable dia. 4mm. GW1600 $0.79	Mono plug 24 x 10mm dia. Cable dia. 4mm. GW1602 $0.79	Mono plug 25 x 9mm dia. Cable dia. 4.7mm. GW1604 $1.16
Stereo plug 24 x 9mm dia. Cable dia. 4mm. GW1601 $0.99	Stereo plug 22 x 10mm dia. Cable dia. 4mm. GW1603 $0.99	Stereo plug 20 x 8.5mm dia. Cable dia. 4mm. GW1605 $1.26
Stereo plug 23 x 8mm dia. Cable dia. 4mm. GW1607 $1.26	4 Pole plug 21 x 10mm dia. Cable dia. 4mm. DK1608 $1.50
Inline mono jack 34 x 10mm dia. Cable dia. 5mm. GW1692 $1.29	Inline mono jack 34 x 10mm dia. Cable dia. 6mm. GW1696 $1.98	Inline Stereo jack 34 x 10mm dia. Cable dia. 5mm. GW1693 $1.29
Mono chassis jack (closed circuit). 4mm mtg. hole. GW1731 $0.79	Mono chassis jack. 8mm W x 9.6mm H x 8mm D. 4mm mtg. Hole. GW1740 $0.60	Mono PC jack c.c. 7.7mm W x 8.5mm H x 10mm D. 4mm mtg. hole GW1746 $0.59
Stereo chassis jack. 8mm W x 9.6mm H x 8mm D. 4mm mtg. Hole. GW1741 $ 0.59

3.5mm Jacks and Plugs
Mono plug 24 x 9.5mm diameter. Cable dia. 4.5mm. GW1610 $0.74	Mono plug 24 x 10mm dia. Cable dia. 4mm. GW1612 $0.74	Metal mono plug 23 x 9mm dia. Cable dia. 5.3mm. GW1616 $0.76
Metal mono plug 25.5 x 9mm dia. Cable dia. 4mm. GW1620 $1.12	Mono right angle plug. GW1627 $0.71	Stereo right angle plug. GW1628 $1.06
Stereo plug. 25.5 x 10mm dia. Cable 5mm dia. GW1611 $0.71	Stereo plug. 25 x 10mm dia. 4.5mm. GW1613 $1.86	Metal stereo plug. 22mm x 9mm dia. Cable dia. 5mm. GW1617 $1.21
Metal stereo plug. 23 x 9mm dia. Cable dia. 4mm GW1621 $1.27	4 Pole plug 21 x 10mm dia. Cable dia. 4mm. GW1629 $1.90	4 Pole plug 21 x 10mm dia. Cable dia. 4mm. GW1630 $2.99

mono jack. 35 x 11.5mm dia. Cable dia. 6mm. GW1700 $0.78	mono jack. 29 x 11mm dia. Cable dia. 5.0mm. DK1702 $0.79	mono jack. 34 x 10.5mm dia. Cable dia. 6mm. GW1706 $1.60
Metal mono jack. 34 x 10mm dia. Cable dia. 4.5mm. 24-353 $1.37	Stereo jack. 29 x 11mm dia. Cable dia. 5.0mm. DK1703 $0.79	Metal stereo jack. 34 x 10mm dia. Cable dia. 6mm. 24-372 $1.37
Metal stereo jack. 34 x 10mm dia. Cable dia. 4.5mm. 24-373 $1.95	Mono chassis jack (closed circuit). 6mm mtg. hole. GW1733 $0.67	Mono closed circuit chassis jack. 6mm mtg. hole. GW1750 $0.71
PC mount mono closed circuit jack. GW1757 $0.68	Mono chassis jack (PC mount also) Mounting hole 6mm diameter. GW1760 $0.72	Stereo closed circuit chassis jack. GW1751 $1.00
Stereo PC mount jack 3P GW1772 $0.89	Stereo PC mount jack with 2 normally closed switches. 6mm mtg. GW1773 $1.19	Stereo PC mount jack. 24-392 $0.59
4 pole jack GW1775 $1.50

1/4" Jacks and Plugs
Black plastic mono plug. 40 x 13mm dia. Cable dia. 8mm. GW1631 $0.95	Mono plug with strain relief. 38 x 13mm dia. Cable dia. 6mm. GW1633 $0.95	Metal mono plug. 33 x12mm dia. Cable dia. 8mm. GW1639 $1.50
Metal mono plug with spring strain relief. 32 x 12mm dia. Cable dia. 6mm. GW1661 $1.50	Metal mono plug. 55 x 17.5mm dia. Cable dia. 10mm. GW1645 $3.90	Metal right angle mono plug. GW1680 $1.50
Plastic right angle mono plug. GW1682 $1.35	Metal right angle mono plug. GW1685 $2.80
plastic stereo plug. 40 x 13mm dia. Cable dia. 7.5mm. GW1632 $1.25	Stereo plug with strain relief. 37 x 13mm dia. Cable dia. 6mm. GW1634 $1.25	Metal stereo plug. 33 x 12mm dia. Cable dia. 8mm. GW1640 $1.75
Metal stereo plug with spring strain relief. 32 x 12mm dia. Cable dia. 6mm. GW1662 $1.75	Metal stereo plug. 55 x 17.5mm dia. Cable dia. 10mm. GW1646 $3.90 (Sold out)	Metal right angle stereo plug. GW1681 $1.75
Plastic right angle stereo plug. GW1683 $1.60	Metal right angle stereo plug. GW1686 $2.90
Mono inline jack. 60 x 14.5mm dia. Cable dia. 8mm. GW1712 $0.99	Mono inline jack. 56 x 14mm dia. Cable dia. 6mm. GW1714 $1.01	Mono inline jack. 54 x 17.5mm dia. Cable dia. 10mm. 24-672 $2.48
Mono inline jack. 56 x 14mm dia. Cable dia. 6mm. GW1724 $2.26	Stereo inline jack. 60 x 14.5mm dia. Cable dia. 8mm. GW1713 $0.99	Stereo inline jack. 56 x 14mm dia. Cable dia. 6mm. GW1715 $1.01
Stereo inline jack. 54 x 17.5mm dia. Cable dia. 10mm. 24-650 $2.48	Stereo inline jack. 56 x 14mm dia. Cable dia. 6mm. GW1725 $2.26
1/4" Chassis Jacks
Mono chassis jack. 9mm mounting hole 24-680 $0.99		Mono chassis jack with switch. 9mm mounting hole 24-681 $0.99
Stereo chassis jack. 9mm mounting hole 24-690 $1.35	Stereo chassis jack with switch. 9mm mounting hole 24-691 $1.35	Stereo chassis jack with 2 SPDT switches. 9mm mounting hole 24-697 $1.99
2P 2-Conductor Open Type 1/4" Mono Jack GW1784 $1.38	3P 3-Conductor Open Type 1/4" Mono Jack GW1786 $1.58	4P 2-Conductor Close Type 1/4" Mono Jack GW1785 $1.58
4P 2-Conductor Close Type 1/4" Mono Jack GW1788 $1.58	6P 3-Conductor Close Type 1/4" Stereo Jack GW1787 $1.58	2P 2-Conductor Open Type 1/4" Mono Jack GW1780 $1.58
6P 3-Conductor Close Type 1/4" Stereo Jack GW1782 $1.58	6P 3-Conductor Close Type 1/4" Stereo Jack GW1789 $1.58

Din Jacks and Plugs

Standard 'Din' Pin Layouts

Inline Din Plugs

25-230
3-position
$1.23

25-240
4-position
$1.39

25-250
5-position
$1.69

25-260
6-position
$1.93

25-280
8-position
$2.32

Inline Din Jacks

25-130
3-position
$1.37

25-140
4-position
$1.57

25-150
5-position
$1.63

25-160
6-position
$1.66

25-180
8-position
$1.90

Chassis Mount Din Jacks

25-330
3-position
$0.99

25-340
4-position
$1.24

25-350
5-position
$1.51

25-360
6-position
$1.57

25-380
8-position
$1.71

Inline Din Plugs

GW2712
2-position
$1.90

Metal Inline Din Plug

25-450
5-position
$3.90

Shielded PC Mount Din Jack

25-358
5-position
$1.83

PC Mount Din Jack

25-359
5-position
$1.08

Mini Din Connectors
Inline Mini Plugs
GW2654-3 3-position $1.39	GW2654-4 4-position $1.39	GW2654-5 5-position $1.39	GW2654-6 6-position $1.49	GW2654-7 7-position $1.49	GW2654-8 8-position $1.66

Inline Mini Jacks
GW2681-3 3-position $1.39	GW2681-4 4-position $1.39	GW2681-5 5-position $1.39	GW2681-6 6-position $1.49	GW2681-7 7-position $1.49	GW2681-8 8-position $1.66

PC Mount Mini Din Jacks			26-350 5-position $1.57	26-360 6-position $1.75
Mini Din Chassis Mount			GW2696-4 4-position (s-video) $1.70	GW2696-6 6-position $1.70	GW2696-8 8-position $1.70

Precision Miniature Connector This miniature precision six contact connector features gold plated contacts, threaded locking ring and precision fit and finish.
25-746 6-position plug $6.07	25-756 6-position jack $7.19

Inline Jacks
25-722 2-Position $1.81	25-723 3-Position $1.87	25-724 4-Position $2.01	25-725 5-Position $2.23	25-726 6-Position $2.41	25-727 7-Position $2.50	25-728 8-Position $2.58

Right Angle Inline Jacks
DK3902-A 2-Position $3.31	DK3902-B 3-Position $3.37	DK3902-C 4-Position $3.51	DK3902-D 5-Position $3.73	DK3902-E 6-Position $3.91	DK3902-F 7-Position $4.00	DK3902-G 8-Position $4.08

Inline Plugs
3903-A 2-Position $2.81	3903-B 3-Position $2.87	3903-C 4-Position $3.01	3903-D 5-Position $3.23	3903-E 6-Position $3.41	3903-F 7-Position $3.50	3903-G 8-Position $3.58
