Variable Speed DC Motor
Model: 4030D-122A
Price: $75.00

Length 11" x Diameter 3.5"
98295
$45.00

Type CYHM
Max Wo: 58
Motor1
$10.00

Description
Type:Permanent magnet DC motor
Weight: 12 ounces Max
VoltageRange: 6 to 36 VDC
Temperature: -20°F to +140°F [-29°C to +60°C] ambient
Output Shaft: Hardened stainless steel
Housing:Zinc-plated steel with zinc die-cast end caps
Magnets:Ceramic 8
Bearings:Oil-impregnated, sintered bronze
Terminations:Two 6" [152.4 mm] 22 gauge leads. Output shaft turns CW when positive (+) voltage is connected to red lead
Armature: Dynamically balanced, skewed for low coggjng
Life:Varies with application / Approximately 2,500 hours based on operating at max. efficiency

• Available with a variety of companion gearheads

• Ball bearings and special lubricants

• Choice of several windings

• Customized output shafts and pulleys

• EMI Filtering

• Optical Encoders / magnetic tachometers Various lead lengths, terminals and connectors

• Voltage Range: 12 and 24 VDC standard 6 to 36 VDC available
